Products – Forklift Mounted Drum Grab



Name：DG1000A Single Gator Grip Heavy Duty Forklift Mounted Drum Grab
Click to view larger
Diagrams：

Products List
Portable Drum Handling Equipment
Drum Dumping Equipment
Hydraulic Drum Stacker
Forklift Mounted Drum Grabber
Forklift and Crane Mounted Drum Handler
Below Hook Drum Lifter
Oil Drum Tool and Accessories
Gas Cylinder Handling Trolley
Mobile Scissor Lift Table
Stationary Lift Platform
Acess Lift Platform
Mini Pallet Stacker
Work Positioner
Platform Hand Trolley
Roll and Reel Handling Equipment
Pallet Tilter
Hoisting and Lifting Equipment
Pallet Truck
Mate Series Lift Trucks
Forklift Attachments

 Business Line: 4007-166-180
 Tel：+86 21 58003681
              +86 21 68014500
 Fax：+86 21 68014262
 Website：http://www.sinoliftdrum.com
 Email：drum@sinolift.com
 Skype：sinolift

Feature：
1.Heavy duty Single Eagle-Grip automatic clamping mechanism for handling
steel and plastic drums in high volume applications.
2.Clamping mechanisms are completely mechanical, requiring no hydraulic or
electrical connections.
3.Replaceable soft wear-resistant protective cushion effectively protects drums and absorbs vibration during driving.
4.Positive action jaws insure safe transporting of drums without damage to drum chimes.
5. Quick adjustable heads allow pickup of various drum heights. Standard heavy duty rubber belt bases support the lower side of the drum eliminating dents or cosmetic marring.

Specifications：

Model
　
DG1000A
Capacity
kg
500*2
Net Weight
kg
71
Overall Size
mm
910*760*870
Load Center
mm
1150
Grab Min. Height
mm
525
Grab Max. Height
mm
750
Grab Middle Height
mm
675--600
Foks leg (length*width)
mm
150*55
Straddle inner Width
mm
430
Staddle outline Width
mm
750
Straddle Length
mm
750
